EJB24015CA Schneider Electric Electronic Components

EJB24015CA on Powermatic Associates
Schneider Electric

Part#:EJB24015CA

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

E-Frame Brkr 15A, 2P, 480Y/277V, 35/65kA, Bolt-on Mnt

Product Details

  • Maximum Operating Voltage
    480Y/277 V AC
  • Device Short Name
    EJB
  • Electrical Connection
    Lugs aluminium
  • Width
    1.96 in (49.78 mm)
  • Number Of Poles
    2
  • Net Weight
    3 lb(US) (1.36 kg)
  • Module Type
    E-Frame
  • Mounting Mode
    Bolt-on
  • Height
    5.66 in (143.76 mm)
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Holding Current
    270 A
  • Trip Unit Rating
    875 A
  • Number Of Spaces Required
    2
  • Line Rated Current
    15 A
  • Number Of Spaces
    2
  • Trip Unit Technology
    Thermal-magnetic
  • Product Or Component Type
    Miniature circuit-breaker
  • Local Signalling
    Trip indicator
  • Depth
    4.05 in (102.87 mm)
  • Breaking Capacity Code
    J
  • Product Destination
    NF panelboard
  • Circuit Breaker Application
    HACR rated HID rated
  • AWG Gauge
    AWG 12...AWG 6 aluminium AWG 14...AWG 6 copper
  • Protection Type
    Overload Short-circuit
  • Breaking Capacity
    65 kA 277 V AC 100 kA 240 V AC 65 kA 480Y/277 V AC 100 kA 120 V AC 100 kA 120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EJB24015CA on Powermatic Associates is $1,489.00. Order now.

EJB24015CA Related Documents

Product Datasheet-1631035110618.pdfInstruction Sheet-1631035110611.pdfCatalog-1631035110615.pdf
