EXN30T65HCU Schneider Electric Industrial Automation Components

Product Details

• Rated Operational Power In VA
  30 kVA
• Secondary Voltage
  208Y/120 V
• Let Through Current
  2.15 kA
• Type Of Cooling
  Natural convection
• X/R Ratio
  0.71
• Net Weight
  361.01 lb(US) (163.75 kg)
• Product Or Component Type
  DOE 2016 energy efficient transformer
• Box Number
  18M
• DOE Efficiency
  98.45 % at 35 % load factor , 167 °F (75.0 °C)
• Height
  28.31 in (719 mm)
• Number Of Mounting Holes
  0.51 in (13 mm)
• Device Application
  Low voltage electrical distribution
• Transformer Type
  Energy efficient
• %IX
  2.24 %
• Primary Operational Current
  28.87 A 83.27 A 30 kVA
• Coil Material
  Copper
• Width
  25.51 in (648 mm)
• Primary Voltage
  600 V delta
• Range Of Product
  Square D
• %IZ
  3.88 %
Device Short Name
DOE 2016
Network Frequency
60 Hz
Basic IMP Level (BIL)
10 kV
Depth
24.69 in (627 mm)
Phase
3 phase
Inrush Current
360 A
Number Of Tap-Offs
2 2.5 % FCAN 4 2.5 % FCBN
Transformer Losses
68 no load (core loss) 973 load loss (coil loss)
Temperature Rise
150 °C 220 °C insulated
Sound Level
6 dB NEMA ST-20 39 dB
Degree Of Protection
UL type 2 UL type 3R, with 7400WS18M19M20M
Electrical Connection
2 Hole Nema Pad secondary 0.44 in (11.1 mm) 4 Hole Nema Pad sec - XO 0.44 in (11.1 mm) 2 Hole Nema Pad primary 0.44 in (11.1 mm)
Mounting Support
Floor Floor, with 7400FMB Ceiling, with 7400CMB18M19M20M Wall, with 7400WMB18M19M20M
Transformer BTU/HR
324 16.6 % 440 25 % 1062 50 % 2100 75 % 3552 100 %
