H225XJGAA Schneider Electric Electronic Components

H225XJGAA on Powermatic Associates
Schneider Electric

Part#:H225XJGAA

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

SW NOT FUSIBLE HD 600V 225A 3P NEMA7,9AC

Product Details

  • Depth
    7.7 in (195.58 mm)
  • Duty Rating
    Heavy duty
  • Mounting Type
    Surface
  • Number Of Poles
    2
  • Tightening Torque
    550 lbf.in (62.14 N.m) (AWG 1/0...750 kcmil)
  • Device Application
    Heavy application
  • Net Weight
    42.99 lb(US) (19.5 kg)
  • Phase
    3 phase
  • Current Rating
    400 A
  • Factory Installed Neutral
    None
  • Wire Size
    AWG 1/0...750 kcmil copper or aluminium
  • Disconnect Type
    Fusible disconnect
  • Width
    10.93 in (277.62 mm)
  • Product
    Single Throw Safety Switch
  • Enclosure Rating
    NEMA 7/9 Cast Aluminium
  • Height
    22.7 in (576.58 mm)
  • Voltage Rating
    250 V DC 240 V AC
  • Maximum Horse Power Rating
    60 hp 240 V at AC 50-60 Hz for 3 phase 125 hp 480 V at AC 50-60 Hz for 3 phase 150 hp 600 V at AC 50-60 Hz for 3 phase

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of H225XJGAA on Powermatic Associates is $6,701.00. Order now.
