HOM60120L225PC Schneider Electric Industrial Automation Components

HOM60120L225PC on Powermatic Associates
Schneider Electric

Part#:HOM60120L225PC

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HOM60120L225PC is a load center designed for single-phase (1PH) networks. It features a welded sheet steel enclosure and a tin-plated aluminum busbar. This load center has dimensions of H1235mm x W362mm x D95mm (H48.62" x W14.25" x D3.74"), with 60 spaces allowing for up to 120 single pole circuits or 60 tandem breakers. It is equipped with lugs for connection, has a rated current of 225A, and operates at a rated voltage of 120Vac/240Vac. The HOM60120L225PC is designed to meet NEMA 1 degree of protection standards.

Product Details

  • Number Of Phases
    1 phase
  • Number Of Spaces
    60
  • Maximum Number Of Single Pole Circuits
    120
  • Max Short Circuit Current Rating
    10 kA
  • Busbar Material
    Tin plated aluminium busbar
  • Rated Current
    225 A
  • Voltage Rating
    120/240 V AC
  • Height
    48.62 in (1235 mm)
  • Maximum Number Of Tandem Breakers
    60
  • Depth
    3.74 in (95 mm)
  • Load Center Type
    Main lugs
  • Electrical Connection
    Lugs
  • Ground Bar
    Grounding bar (ordered separately)
  • Product Type
    Load Center
  • Marketing Trade Name
    Homeline
  • Wiring Configuration
    3-wire
  • Enclosure Rating
    NEMA 1 indoor
  • Surface Finish
    Baked enamel Gray
  • Cover Type
    Combination flush/surface cover
  • Box Number
    25
  • Width
    14.25 in (362 mm)
  • Enclosure Material
    Welded sheet steel
  • Wire Size
    AWG 4...250 kcmil copper AWG 4...300 kcmil aluminium

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HOM60120L225PC on Powermatic Associates is $974.16. Order now.

HOM60120L225PC Related Documents

Instruction Sheet-1631040886357.pdfProduct Datasheet-1631040886359.pdfCatalog-1631040886364.pdf
