ILM1003P02F0000 Schneider Electric Industrial Automation Components

ILM1003P02F0000 on Powermatic Associates
Schneider Electric

Part#:ILM1003P02F0000

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric ILM1003P02F0000 is an AC servo motor within the Servo motors sub-range, featuring an integrated servo drive and motor. It is designed with an absolute multi-turn 128ppr SinCos encoder, a smooth shaft, a holding brake, and triple (3) motor stacks. This model utilizes the HIPERFACE communication protocol and operates at a rated current of 2.4A. It is mounted via a 100x100mm flange, has a net width of 100 mm, and is protected to a degree of IP54. The motor delivers a torque of 3.5Nm, with a rated active power of 1.1kW (1100W), and can achieve a maximum torque of 28.3Nm. It is capable of reaching a rotational speed of 3000rpm and has a stall torque of 5.8Nm.

Product Details

  • Peak Stall Torque
    250.48 lbf.in (28.3 N.m)
  • Second Shaft
    Without second shaft end
  • Torque Constant
    1.61 N.m/A 248 °F (120 °C)
  • Number Of Motor Stacks
    3
  • Continuous Stall Current
    3.6 A
  • Nominal Speed
    3000 rpm
  • Speed Feedback Resolution
    128 periods
  • Shaft Length
    1.57 in (40 mm)
  • Back Emf Constant
    103 V/krpm 68 °F (20 °C)
  • Centring Collar Diameter
    3.74 in (95 mm)
  • Device Short Name
    ILM
  • Maximum Current Irms
    21.2 A
  • Mounting Support
    International standard flange
  • Maximum Axial Force Fa
    0.2 x Fr
  • [Us] Rated Supply Voltage
    250...700 V
  • Shaft End
    Untapped
  • Motor Flange Size
    3.94 in (100 mm)
  • Length
    12.40 in (315 mm)
  • Nominal Torque
    30.98 lbf.in (3.5 N.m)
  • Product Or Component Type
    Servo motor integrated drive
  • Holding Brake
    With
  • Net Weight
    19.62 lb(US) (8.9 kg)
  • Continuous Stall Torque
    51.33 lbf.in (5.8 N.m)
  • Number Of Motor Poles
    8
  • Shaft Diameter
    0.75 in (19 mm)
  • Number Of Mounting Holes
    4
  • Range Of Product
    PacDrive 3
  • Key Width
    1.18 in (30 mm)
  • Rotor Inertia
    3.92 kg.cm²
  • Centring Collar Depth
    0.14 in (3.5 mm)
  • Feedback Type
    Absolute multiturn SinCos Hiperface
  • Mounting Holes Diameter
    0.35 in (9 mm)
  • Nominal Output Power
    1100 W
  • Line Rated Current
    2.4 A
  • Holding Torque
    79.66 lbf.in (9 N.m) holding brake
  • Type Of Cooling
    Natural convection
  • Circle Diameter Of The Mounting Holes
    4.53 in (115 mm)
  • Stator Resistance
    2.6 Ohm 68 °F (20 °C) Ph/Ph 1.81 Ohm 248 °F (120 °C) Ph/N
  • Stator Inductance
    15.6 mH 68 °F (20 °C) Ph/Ph 7.8 mH 248 °F (120 °C) Ph/N
  • Maximum Radial Force Fr
    1050 N 1000 rpm 830 N 2000 rpm 730 N 3000 rpm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of ILM1003P02F0000 on Powermatic Associates is $4,803.42. Order now.
