QBL22080 Schneider Electric Industrial Automation Components

QBL22080 on Powermatic Associates
Schneider Electric

Part#:QBL22080

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QBL22080 is a Moulded Case Circuit Breaker (MCCB) designed for individual unit mount on plate. It features a PowerPact Q-Frame 250 TMD 2P 80A 240Vac with a 10kA short circuit breaking rating and lugs on both load and line sides for connection. This MCCB has a net height of 114 mm, a net width of 164 mm, and a net depth of 100 mm. It operates with a rated current of 80A and a rated voltage of 240Vac. The QBL22080 is equipped with two poles (2P) and offers thermal protection for overload and magnetic protection for short-circuits, with a trip current rating of 80 AT. Its frame current rating is 250 AF, and it utilizes a thermal-magnetic trip unit type without a display. The protection settings are fixed, with over-current protection at 80A, short-circuit hold current fixed at 1000A, and short-circuit trip current fixed at 1800A.

Product Details

  • Breaking Capacity Code
    B
  • Width
    4.5 in (114.30 mm)
  • Magnetic Tripping Current
    1800 A
  • Height
    6.47 in (164.34 mm)
  • Continuous Current Rating
    80 %
  • Magnetic Hold Current
    1000 A
  • Depth
    3.93 in (99.82 mm)
  • Product Or Component Type
    Circuit breaker
  • Trip Unit Technology
    Thermal-magnetic
  • Tightening Torque
    247.82 lbf.in (28 N.m) 0.04…0.23 in² (25…150 mm²) (AWG 4...300 kcmil)
  • Line Rated Current
    80 A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QBL22080 on Powermatic Associates is $711.00. Order now.
