Part#:QBL22000S22

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

POWERPACT AUTOMATIC MOULDED CASE SWITCH 240V 225 A Q-Frame

Product Details

  • Breaking Capacity Code
    B
  • Width
    16.54 in (420.12 mm)
  • Product Or Component Type
    Automatic switch
  • Short-Circuit Withstand
    10 kA 240 V UL 489
  • [Ue] Rated Operational Voltage
    240 V AC
  • Poles Description
    2P
  • Range Of Product
    PowerPact Q
  • Tightening Torque
    247.82 lbf.in (28 N.m) 0.04…0.23 in² (25…150 mm²) (AWG 4...300 kcmil)
  • Mounting Mode
    Unit mount
  • Height
    16.24 in (412.50 mm)
  • Magnetic Tripping Current
    4500 A
  • Circuit Breaker Type
    Q-Frame
  • Trip Unit Technology
    Magnetic
  • Line Rated Current
    225 A
  • AWG Gauge
    AWG 4...300 kcmil aluminium/copper)
  • Depth
    14.49 in (368.05 mm)
  • Electrical Connection
    Lugs line Lugs load

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QBL22000S22 on Powermatic Associates is $660.00. Order now.
