QBP22175TP Schneider Electric Electronic Components

QBP22175TP on Powermatic Associates
Schneider Electric

Part#:QBP22175TP

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

PowerPact Q - molded case circuit breaker - 2-pole - 10 kA - 240 V - 175 A

Product Details

  • Magnetic Hold Current
    1200 A
  • Width
    4.5 in (114.30 mm)
  • Product Or Component Type
    Circuit breaker
  • Depth
    3.93 in (99.82 mm)
  • Line Rated Current
    175 A
  • Trip Unit Technology
    Thermal-magnetic
  • Magnetic Tripping Current
    2400 A
  • Height
    6.47 in (164.34 mm)
  • Breaking Capacity Code
    B
  • Continuous Current Rating
    80 %
  • Tightening Torque
    247.82 lbf.in (28 N.m) 0.04…0.23 in² (25…150 mm²) (AWG 4...300 kcmil)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QBP22175TP on Powermatic Associates is $474.00. Order now.
