QOU21251021 Schneider Electric Industrial Automation Components

QOU21251021 on Powermatic Associates
Schneider Electric

Part#:QOU21251021

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOU21251021 is a miniature circuit breaker (MCB) designed for unit mount installation. It features a shunt trip coil, facilitating remote tripping of the breaker. This MCB is rated for a current of 125A and accommodates slotted box lugs connections on both the load and line sides. It supports a cross-section of 12-2/0AWG for one cable, either aluminum or copper. The QOU21251021 is a 2-pole breaker compatible with DC voltages up to 60Vdc and AC voltages of 120V and 240V. Its control voltage ranges from 120Vac to 208Vac. The short circuit breaking rating stands at 10kA for 240Vac and 5kA for 60Vdc, with box lugs as the type of terminals.

Product Details

  • Mounting Mode
    Unit mount
  • Tightening Torque
    45 lbf.in (5.08 N.m) (AWG 12...AWG 2/0)
  • Height
    4.45 in (113.03 mm)
  • Range Of Product
    QOU
  • Line Rated Current
    125 A
  • Depth
    2.95 in (74.93 mm)
  • Product Or Component Type
    Miniature circuit-breaker
  • Width
    2.25 in (57.15 mm)
  • Circuit Breaker Type
    Standard
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium/copper
  • Electrical Connection
    Slotted box lugs, line side Slotted box lugs, load side
  • [Ue] Rated Operational Voltage
    120/240 V AC 120 V AC 60 V DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOU21251021 on Powermatic Associates is $641.00. Order now.
