XB4BA22 Schneider Electric Industrial Automation Components

Product Details

• Operator Profile
  Black flush, unmarked
• Contacts Usage
  Standard contacts
• Type Of Operator
  spring return
• Width
  1.18 in (30 mm)
• Tightening Torque
  7.08…10.62 lbf.in (0.8…1.2 N.m) EN 60947-1
• Sale Per Indivisible Quantity
  1
• Height
  1.85 in (47 mm)
• [Ith] Conventional Free Air Thermal Current
  10 A EN/IEC 60947-5-1
• Range Of Product
  Harmony XB4
• Contacts Type And Composition
  1 NC
• Net Weight
  0.18 lb(US) (0.08 kg)
• Contacts Material
  Silver alloy (Ag/Ni)
• Short-Circuit Protection
  10 A cartridge fuse gG EN/IEC 60947-5-1
• Shape Of Signaling Unit Head
  Round
• Terminals Description ISO N°1
  (11-12)NC
• Mechanical Durability
  10000000 cycles
• Device Short Name
  XB4
• Depth
  2.05 in (52 mm)
• Device Presentation
  Complete product
• Product Or Component Type
  Push-button
Head Type
Standard
Resistance To High Pressure Washer
1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m
[Uimp] Rated Impulse Withstand Voltage
6 kV EN/IEC 60947-1
Mounting Diameter
0.87 in (22 mm)
Contact Operation
Slow-break
Positive Opening
Without
Operating Force
3.5 N NC changing electrical state
Bezel Material
Chromium plated metal
Fixing Collar Material
Zamak
[Ui] Rated Insulation Voltage
600 V 3)EN/IEC 60947-1
Operating Travel
0.06 in (1.5 mm) NC changing electrical state) 0.17 in (4.3 mm) total travel)
Electrical Reliability
Λ < 10exp(-6) 5 V 1 mA in clean environment EN/IEC 60947-5-4 Λ < 10exp(-8) 17 V 5 mA in clean environment EN/IEC 60947-5-4
Connections - Terminals
Screw clamp terminals, <= 2 x 1.5 mm² with cable end EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end EN/IEC 60947-1
Shape Of Screw Head
Cross Philips no 1 Cross pozidriv No 1 Slotted flat Ø 4 mm Slotted flat Ø 5.5 mm
Electrical Durability
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycle
[Ie] Rated Operational Current
3 A 240 V, AC-15, A600 EN/IEC 60947-5-1 6 A 120 V, AC-15, A600 EN/IEC 60947-5-1 0.1 A 600 V, DC-13, Q600 EN/IEC 60947-5-1 0.27 A 250 V, DC-13, Q600 EN/IEC 60947-5-1 0.55 A 125 V, DC-13, Q600 EN/IEC 60947-5-1 1.2 A 600 V, AC-15, A6
