XB4BW36M5 Schneider Electric Electronic Components

Product Details

• Bezel Material
  Chromium plated metal
• Shape Of Signaling Unit Head
  Round
• Height
  1.85 in (47 mm)
• Contacts Material
  Silver alloy (Ag/Ni)
• Service Life
  100000 h at rated voltage and 25 °C
• Fixing Collar Material
  Zamak
• Light Source
  Protected LED
• [Ui] Rated Insulation Voltage
  600 V 3)EN/IEC 60947-1
• Surge Withstand
  1 kV IEC 61000-4-5
• Device Short Name
  XB4
• Width
  1.18 in (30 mm)
• Short-Circuit Protection
  10 A cartridge fuse gG EN/IEC 60947-5-1
• Head Type
  Standard
• Bulb Base
  Integral LED
• Resistance To High Pressure Washer
  1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m
• Contacts Type And Composition
  1 NO + 1 NC
• Mechanical Durability
  10000000 cycles
• Supply Voltage Limits
  195…264 V AC
• Mounting Diameter
  0.87 in (22 mm)
• Operator Profile
  Blue flush
Net Weight
0.21 lb(US) (0.097 kg)
Tightening Torque
7.08…10.62 lbf.in (0.8…1.2 N.m) EN 60947-1
Current Consumption
14 mA
Product Or Component Type
Illuminated push-button
[Us] Rated Supply Voltage
220...240 V AC 50/60 Hz
Positive Opening
With conforming to EN/IEC 60947-5-1 appendix K
Signalling Type
Steady
Sale Per Indivisible Quantity
1
Type Of Operator
spring return
Depth
3.98 in (101 mm)
Range Of Product
Harmony XB4
Contact Operation
Slow-break
Contacts Usage
Standard contacts
[Ith] Conventional Free Air Thermal Current
10 A EN/IEC 60947-5-1
Device Presentation
Complete product
Operator Additional Information
With plain lens
[Uimp] Rated Impulse Withstand Voltage
6 kV EN/IEC 60947-1
Connections - Terminals
Screw clamp terminals, <= 2 x 1.5 mm² with cable end EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end EN/IEC 60947-1
Terminals Description ISO N°1
(21-22)NC (13-14)NO
Operating Force
3.5 N NC changing electrical state 3.8 N
Electrical Reliability
Λ < 10exp(-6) 5 V 1 mA in clean environment EN/IEC 60947-5-4 Λ < 10exp(-8) 17 V 5 mA in clean environment EN/IEC 60947-5-4
Operating Travel
0.06 in (1.5 mm) NC changing electrical state) 0.10 in (2.6 mm) NO changing electrical state) 0.17 in (4.3 mm) total travel)
Shape Of Screw Head
Cross Philips no 1 Cross pozidriv No 1 Slotted flat Ø 4 mm Slotted flat Ø 5.5 mm
Electrical Durability
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycle
[Ie] Rated Operational Current
3 A 240 V, AC-15, A600 EN/IEC 60947-5-1 6 A 120 V, AC-15, A600 EN/IEC 60947-5-1 0.1 A 600 V, DC-13, Q600 EN/IEC 60947-5-1 0.27 A 250 V, DC-13, Q600 EN/IEC 60947-5-1 0.55 A 125 V, DC-13, Q600 EN/IEC 60947-5-1 1.2 A 600 V, AC-15, A6
