REI-E-112I8T-2B2500-C Turck Industrial Automation Components
Part#:REI-E-112I8T-2B2500-C
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Discontinued
Product description
REI-E-112I8T-2B2500-C Turck - REI-E-112I8T-2B2500-C Incremental Encoder, Efficiency Line
Product Details
- Housing material Aluminium
- Encoder line Efficiency-Line
- Output type Incremental
- Flange diameter Ø 40 mm
- Resolution, incremental 2500 ppr
- Technology Optical
- Electrical connection Cable
- Flange type Flange with mounting element
- Shaft Type Hollow shaft
- Shaft diameter D [mm] 8 mm
- Protection class IP64
- Ambient temperature -20…+70 °C
- Protection class shaft IP64
- Output function Push-Pull/HTL, with inverted signals
- Operating voltage 10…30 VDC
- Country of Origin India
- Weight 170 grams
- Operating Voltage 10 volts, 30 volts
- Ambient Temperature -20 degrees celsius, 70 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Incremental Encoder, Efficiency Line, Resolution, incremental 2500 ppr, Flange with mounting element, Ø 40 mm, Blind hole hollow shaft, Ø 8mm, Optical measuring principle, Shaft material: stainless steel, Protection class IP64 on housing and shaft side, ‐20…+70 °C, Max. 4500 rpm, 10…30 VDC, Cable connection, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 2500 pulses per revolution
