RI-10SA1Z4-2B1024-H1181 Turck Industrial Automation Components
Part#:RI-10SA1Z4-2B1024-H1181
Alt. Part#:1545874
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
RI-10SA1Z4-2B1024-H1181 Turck - RI-10SA1Z4-2B1024-H1181 Incremental Shaft Encoder, Industrial Line
Product Details
- RoHS Yes
- Country Of Origin USA
- HTS Code 9029108000
- Encoder line Industrial-Line
- Resolution, incremental 1024 ppr
- Output type Incremental
- Flange diameter Ø 50.8 mm
- Flange type Rectangular flange
- Technology Optical
- Shaft diameter D [mm] 9.525 mm
- Housing material Die-cast zinc
- Operating voltage 5…30 VDC
- Ambient temperature -40…+85 °C
- Shaft Type Solid shaft
- Protection class IP67
- Output function Push-Pull 7272, with inverted signals
- Electrical connection Connector
- Protection class shaft IP67
- Ambient Temperature -40 degrees celsius, 85 degrees celsius
- Operating Voltage 30 volts
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of RI-10SA1Z4-2B1024-H1181 on Powermatic Associates is $390.00. Order now.
About the product
Incremental Shaft Encoder, Industrial Line, Resolution, incremental 1024 ppr, Square flange, Ø 50,8 mm, Solid shaft, Ø 3/8” x 5/8”, Optical measuring principle, Shaft material, stainless steel, , Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 6000 rpm (continuous operation 3000 rpm), 5…30 VDC, Male connector, M12 x 1, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 1024 pulses per revolution
