RI-12H12S1-2B2048-H1181 Turck Industrial Automation Components
Part#:RI-12H12S1-2B2048-H1181
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Discontinued
Product description
RI-12H12S1-2B2048-H1181 Turck - RI-12H12S1-2B2048-H1181 Incremental Encoder, Industrial Line
Product Details
- Ambient temperature -40…+85 °C
- Resolution, incremental 2048 ppr
- Technology Optical
- Encoder line Industrial-Line
- Flange type Flange with mounting element
- Electrical connection Connector, M12 × 1
- Operating voltage 10…30 VDC
- Housing material Die-cast zinc
- Shaft diameter D [mm] 12 mm
- Output type Incremental
- Protection class IP67
- Shaft Type Hollow shaft
- Output function Push-Pull/HTL, with inverted signals
- Protection class shaft IP67
- Operating Voltage 10 volts, 30 volts
- Ambient Temperature -40 degrees celsius, 85 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Incremental Encoder, Industrial Line, Resolution, incremental 2048 ppr, Flange with tether arm for 40-75mm mounting diameters, Hollow shaft, Ø 12 mm, Optical measuring principle, Shaft material: stainless steel, Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 6000 rpm (continuous operation 3000 rpm), 10…30 VDC, Male connector, M12 x 1, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 2048 pulses per revolution
