2606-3106/020-000 WAGO Industrial Automation Components
Part#:2606-3106/020-000
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
2606-3106/020-000 WAGO - PCB terminal block; lever; Pin spacing 7.5 mm; W pinning; 6-pole; Push-in CAGE CLAMP®; gray
Product Details
- Weight 25.53000671 g
- Country Of Origin Germany
- HTS Code 85369010000
- Contact Type Tin
- Width 1.884 inches, 47.85 millimeters
- Height 1.22 inches, 31 millimeters
- Actuator Lever
- Strip Length 0.51 inches, 13 millimeters
- Country of Origin Germany
- Voltage 600 volts, 800 volts
- Conductor Size 10 millimeters, 8 american wire gauge
- Package Type Box
- Color Gray
- Operating Temperature 105 degrees celsius
- Contact Material Copper
- Weight 25.530 grams
- Flammability Class V0
- Depth 0.945 inches, 24 millimeters
- Current 31 amperes, 41 amperes
- Insulation Material Polyamide
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2606-3106/020-000 on Powermatic Associates is $10.39. Order now.
About the product
WAGO 2606-3106/020-000 is an automation part with a short circuit breaking rating and electrical data adhering to IEC/EN 60664-1 standards, including a nominal voltage of 800V (III/3), rated impulse voltage of 8kV (III/3), rated voltage of 1000V (III/2), and a rated current of 41A. It features UL 1059 approval with rated voltages of 600V and rated currents of 31A for both Use Group B and C, alongside CSA approvals with identical ratings for these groups. This part offers 6 connection points, a single connection type with push-in CAGE CLAMP technology, lever actuation, and accommodates solid and fine-stranded conductors ranging from 0.2 to 10mm2 or 24 to 8 AWG, including various ferrule types. The physical specifications include a pin spacing of 7.5mm, dimensions of 47.85mm in width, 31mm in height, and a depth of 24mm, with a solder pin length of 4mm. It is made from Polyamide (PA66) in gray, with a chrome-nickel spring steel clamping spring, electrolytic copper contacts with tin plating, and an orange actuator. The part operates within a temperature range of -60 to +105°C, is RoHS compliant, and comes in a box of 40 pieces with the country of origin being Germany.
