X20BM12 B&R Electronic Components

Product Details

• Pitch
  12.5+0.2 mm
• Mounting orientation Horizontal
  Yes
• Certifications UKCA
  Yes
• Certifications KC
  Yes
• Relative humidity Transport
  5 to 95%, non-condensing
• Certifications CE
  Yes
• Certifications HazLoc
  cCSAus 244665; Process control equipment; for hazardous locations; Class I, Division 2, Groups ABCD, T5
• Mounting orientation Vertical
  Yes
• Degree of protection per EN 60529
  IP20
• Certifications ABS
  Yes
• Installation elevation above sea level >2000 m
  Reduction of ambient temperature by 0.5°C per 100 m
• Bus module
  Bus module, 240 VAC keyed, internal I/O power supply connected through
• Power consumption Bus
  0.13 W
• Certifications UL
  cULus E115267; Industrial control equipment
• Certifications DNV
  Temperature: B (0 - 55°C); Humidity: B (up to 100%); Vibration: B (4 g); EMC: B (bridge and open deck)
• Installation elevation above sea level 0 to 2000 m
  No limitation
• Temperature Derating
  -
• Temperature Operation Horizontal mounting orientation
  -25 to 60°C
• Permissible contact load
  10 A
• Certifications KR
  Yes
Temperature Storage
-40 to 85°C
Temperature Operation Vertical mounting orientation
-25 to 50°C
Nominal voltage
24 VDC
Certifications LR
ENV1
Relative humidity Storage
5 to 95%, non-condensing
Certifications ATEX
Zone 2, II 3G Ex nA nC IIA T5 Gc; IP20, Ta (see X20 user's manual); FTZÚ 09 ATEX 0083X
Relative humidity Operation
5 to 95%, non-condensing
Power consumption Internal I/O
-
Certifications EAC
Yes
Temperature Transport
-40 to 85°C
