X20EM0613 B&R Electronic Components

Product Details

• Weight
  475 g
• Cooling
  Fanless
• FPU
  Yes
• Power consumption Internal I/O
  0.56 W
• Application memory Guaranteed erase/write cycles
  20,000
• Interface IF4 Variant
  Type A
• Interface IF7 Terminating resistor
  Integrated in PLC, not switchable
• Relative humidity Storage
  5 to 95%, non-condensing
• Application memory Writable data amount Results for 5 years
  21.9 GB/day
• Interface IF3 Transfer Auto-MDI/MDIX
  Yes
• Power consumption for X2X Link power supply
  0.6 W
• Redundant operation
  Yes
• Diagnostics CPU function
  Yes, using LED status indicator
• Certifications UKCA
  Yes
• Interface IF3 Fieldbus
  POWERLINK (V2) managing or controlled node
• Interface IF3 Line length
  Max. 100 m between 2 stations (segment length)
• Mounting orientation Vertical
  Yes
• Temperature Derating
  -
• Interface IF2 Transfer Full-duplex
  Yes
• Temperature Operation Horizontal mounting orientation
  -25 to 60°C
Input voltage
24 VDC -20% / +25%
Real-time clock
Retention for at least 300 hours, typ. 1000 hours at 25°C, 1 s resolution, <30 s/month accuracy at 25°C
Shortest task class cycle time
100 µs
Support Visual Components support
Yes
Application memory Error-correcting code (ECC)
Yes
Interface IF3 Transfer rate
100 Mbit/s
Interface IF7 Max. distance
1000 m
Temperature Transport
-40 to 70°C
Application memory Writable data amount Guaranteed
40 TB
Interface IF3 Transfer Full-duplex
POWERLINK mode: No / Ethernet mode: Yes
B&R ID code
0x288F
Integrated I/O processor
Processes I/O data points in the background
Electrical isolation
Ethernet (IF2), POWERLINK (IF3), X2X (IF6) and RS485 (IF7) isolated from each other, from other interfaces and from PLC ; I/O to PLC isolated from all interfaces; USB (IF4 and IF5) not isolated from PLC
Certifications CE
Yes
Interface IF2 Signal
Ethernet
Interface IF7 Variant
Connection via 6-pin terminal block
Installation elevation above sea level >2000 m
Reduction of ambient temperature by 0.6°C per 100 m
Dimensions Height
124 mm
Interface IF2 Transfer Autonegotiation
Yes
Temperature Operation Vertical mounting orientation
-25 to 50°C
Status indicators
CPU function, Ethernet, POWERLINK, RS485, I/O power supply
Permissible contact load
10 A
Diagnostics POWERLINK
Yes, using LED status indicator
Processor Clock frequency
1.3 GHz
Interface IF2 Line length
Max. 100 m between 2 stations (segment length)
Interface IF4 Max. output current
0.5 A
Interface IF5 Variant
Type A
Relative humidity Operation
5 to 95%, non-condensing
Processor L1 cache Program code
32 kB
Interfaces
1x RS485, 1x Ethernet (2-port switch), 1x POWERLINK (V2), 2x USB, 1x X2X Link
Parallel connection
Yes
Remanent variables
Max. 64 kB, retention >10 years
Diagnostics I/O power supply
Yes, using software and LED status indicator
Diagnostics Temperature
Yes, using software register
Application memory Data retention
10 years
Interface IF3 Type
Type 4
Interface IF7 Transfer rate
Max. 115.2 kbit/s
Dimensions Width
55 mm
Interface IF2 Transfer Half-duplex
Yes
System module
Controller
Fuse
Integrated, cannot be replaced
Modular interface slots
0
Support Controller redundancy
No
Application memory Type
2 GB eMMC flash memory
Interface IF5 Type
USB 1.1/2.0
Interface IF7 Signal
RS485
Temperature Storage
-40 to 70°C
Interface IF2 Transfer Physical layer
10BASE-T/100BASE-TX
Interface IF3 Transfer Autonegotiation
Yes
Power consumption
4.7 W
Nominal output voltage
24 VDC
Degree of protection per EN 60529
IP20
Processor Type
Atom E3915
Interface IF2 Transfer rate
10/100 Mbit/s
Interface IF4 Type
USB 1.1/2.0
Interface IF5 Max. output current
0.5 A
Relative humidity Transport
5 to 95%, non-condensing
Interface IF2 Transfer Auto-MDI/MDIX
Yes
Reverse polarity protection
Yes
Typical instruction cycle time
0.0015 µs
Diagnostics Ethernet
Yes, using LED status indicator
Support ACOPOS support
Yes
Standard memory RAM
1 GB LPDDR4 SDRAM
Interface IF2 Variant
2x shielded RJ45 (switch)
Interface IF6 Fieldbus
X2X Link master
Installation elevation above sea level 0 to 2000 m
No limitation
Processor L1 cache Data code
24 kB
Interface IF3 Transfer Half-duplex
Yes
Input current
Max. 1.4 A
Nominal output power
3.5 W
Note
X20 end cover plate (right) included in delivery ; 2- and 6-pin terminal block included in delivery
Support Storage health data support
Yes
Processor L2 cache
1 MB
Interface IF3 Variant
1x RJ45 shielded
Mounting orientation Horizontal
Yes
Dimensions Depth
92 mm
Interface IF3 Transfer Physical layer
100BASE-TX
