Part#:QT50R-KR-AFS

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Banner Engineering QT50R-KR-AFS is a collision-avoidance adjustable-field radar sensor designed with a time-of-flight system and approved by Korea Telecom. It operates within an ambient air temperature range of -40 to +65°C and is equipped with a pre-wired 6.5ft / 2m cable terminated with bare end flying leads for connectivity. This sensor falls within the QT50R-AF2 series and offers a degree of protection rated at IP67, making it suitable for various environmental conditions. It requires a supply voltage of 12Vdc-24Vdc and features a rectangular shape with an ABS / Polycarbonate (PC) housing. The QT50R-KR-AFS has a sensing distance of 2 to 3.5m and supports both Normally Open (NO) and Normally Closed (NC) operating modes. It includes 1 x digital output (PNP/NPN transistor) and is equipped with protection functions against reverse polarity and short-circuit.

Product Details

  • Power
    DC
  • Primary Housing Material
    ABS/Polycarbonate
  • Output Protection
    Protected against short circuit
  • PROFINET
    No
  • Sensing Mode (General)
    Proximity
  • Connection
    Flying Leads
  • Max Discrete (Switched) Output (mA)
    150
  • Feature: Chemical Resistant
    No
  • Wireless
    No
  • Sensing Beam
    Radar
  • PC Configurable
    No
  • Max Sensing Distance (mm)
    3500
  • Minimum Sensing Distance (mm)
    2000
  • IP Rating
    IP67
  • Max Operating Temperature (°C)
    65
  • IO Link
    No
  • Common Ethernet Protocol
    No
  • 1-wire Serial Interface
    No
  • Cert: Korea
    Yes
  • Max Measurement Range
    <=5 m
  • Quick Disconnect Type
    No QD
  • Delay at Power-up (ms)
    2000
  • Feature: Timing (Hold/Delay)
    No
  • RS-232
    No
  • Cable Length (m)
    2
  • Radar Beam Pattern (H x V °)
    90 x 76
  • Number of Pins
    5
  • Supply Protection Circuitry
    Protected against reverse polarity and transient overvoltages
  • SSI
    No
  • Operating Frequency
    24 GHz
  • Device Type
    Sensor
  • Power Supply
    12-24 V dc
  • Minimum Response Time (ms)
    30
  • Profibus
    No
  • Sensing Mode (Detailed)
    Time of Flight
  • Indicator
    LED(s)
  • Adjustments
    Dip Switch
  • Power/Current Consumption (exclusive of load)
    < 100 mA
  • RS-422
    No
  • Housing Style
    Rectangular
  • Input/Output
    Discrete
  • Discrete (Switched) Outputs
    Bipolar (NPN & PNP)
  • Min Operating Temperature (°C)
    -40
  • RS-485
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
