SLSRBR30-600Q8 Banner Safety Light Curtains
Part#:SLSRBR30-600Q8
Alt. Part#:75841
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
EZ-SCREEN Remote Blanking Receiver; Resolution: 30 mm; Range: 18 m (60 ft); Defined Area: 600 mm (23.6 in); Housing Length: 671 mm (26.4 in); Connection: 8-pin M12 Connector
Product Details
- Weight 716.67536 g
- Country Of Origin MX
- Trip/Latch Output Selectable
- Feature: ESD Safe No
- Feature: End-to-End Sensing No
- Test Input No
- Housing Material Aluminum; Zinc; Acrylic
- Supply Current 275 mA max.
- Feature: Integral Muting No
- OSSD Rating 24 V dc at 0.5 A each
- Auxiliary Output Yes
- Fault Output No
- Vibration 10-55 Hz at 0.35 mm
- Short Protection Yes
- System Type Receiver
- Shock 10g at 16ms (6000 cycles)
- Scan Code Selectable
- Electrical Safety Class III
- SIL Rating SIL3; CL3
- Response Time 13
- Resolution (mm) 30
- Reduced Resolution Yes
- Recovery Time 25-152 / 81-495
- Operating Temperature 0 to +55 deg. C; RH 95%
- PL Rating Ple
- Operating Voltage 24 V dc +/- 15%
- Operating Distance (m) 0.1 - 18
- IP Rating IP65
- Number of Pins (Receiver/Emitter) 8
- Housing Finish Yellow Polyester
- Fixed Blanking Yes
- External Monitoring Device 1 or 2 Channel
- Overall Length (mm) 522
- Defined Area Height (mm) 600
- Dimensions WxD (mm) 36 x 45.2
- Connector Type M12
- Effective Aperture Angle Type 4 Per IEC 61496-2
- Primary Housing Material Aluminum
- Safety Level Type 4
- low-profile No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SLSRBR30-600Q8 on Powermatic Associates is $1,441.00. Order now.
About the product
Banner Engineering SLSRBR30-600Q8 is a safety light curtain from the SLS series designed for hand detection with a resolution of 30mm. This receiver unit is housed in yellow aluminum with acrylic lens and die-cast zinc end caps. It features a protective height of 600mm and is pre-equipped with an 8-pin Euro-style M12 connector for connectivity. The device operates on a 24Vdc supply voltage and can function within an ambient air temperature range of 0 to +55°C. With an IP65 degree of protection, it is suited for various industrial environments. The SLSRBR30-600Q8 offers a sensing distance of 10cm to 18m and includes two digital outputs (24Vdc; 500mA; sourcing; redundant OSSD solid-state outputs) and one digital output (24Vdc; 75mA; sourcing/PNP transistor) for enhanced functionality. Additionally, it has one digital input for EDM and one for RESET, both accepting 10Vdc to 30Vdc. The unit's response time is 15ms, and its dimensions are 36mm in width, 671mm in height, and 46mm in depth, with a 30mm beam spacing/pitch.
