Part#:SMU31RLQDP

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

SMU31RLQDP 6IN 5-PIN MICRO LONG RANGE RECEIVER

Product Details

  • Feature: Audible
    No
  • IO Link
    No
  • DeviceNet
    No
  • Feature: Chemical Resistant
    No
  • Feature: Encapsulated
    No
  • Feature: Hazardous Area
    No
  • Barrel Diameter (mm)
    18
  • Indicator
    LEDs
  • Adjustments
    Potentiometer
  • Opposed Mode Emitter/Receiver
    Receiver
  • Feature: Timing (Hold/Delay)
    No
  • Lens Material
    Acrylic
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • NEMA Rating
    NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13
  • Number of Pins
    5
  • Repeatability (µs)
    N/A
  • IP Rating
    IP67
  • Delay at Power-up (ms)
    N/A
  • Special Feature: Remote Teach
    No
  • Special Feature: Water Detection
    No
  • Max Op. Temp. (°C)
    55
  • Special Feature: Intrinsically Safe
    No
  • Output response time (ms)
    20
  • Quick Disconnect Type
    1/2 in. (Micro)
  • Power Supply/Supply Voltage
    24-240 V ac/dc
  • Min Op. Temp. (°C)
    -20
  • Outputs
    SPDT e/m Relay
  • Connection
    Pigtail QD
  • Operation
    Light/Dark Operate
  • Max Sensing Distance (mm)
    30000
  • Input/Output
    E/M Relay
  • Primary Housing Material
    Thermoplastic
  • Sensing Mode (General)
    Opposed
  • Sensing Beam
    Infrared LED
  • Sensing Mode (Detailed)
    Receiver
  • Power
    AC/DC Universal
  • Housing Style
    Rectangular w/M18 Mount

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
