547153 Festo Directional Control Valves
Part#:547153
Alt. Part#:VSVA-B-T32H-AZH-A2-5C1
Manufacturer:Festo
Category:Directional Control Valves
Product Lifecycle:Active
Product description
solenoid valve VSVA-B-T32H-AZH-A2-5C1 With square plug, shape C Valve function: 2x3/2 open/closed, monostable, Type of actuation: electrical, Valve size: 18 mm, Standard nominal flow rate: 400 l/min, Operating pressure: 2 - 10 bar
Product Details
- Valve size 18 mm
- Design Piston gate valve
- Nominal width 5 mm
- Mounting position Any
- Type of control Pilot-controlled
- Flow rate of pneumatic valve 600 l/min
- Coil characteristics 12 V DC: 1.8 W
- Corrosion resistance class (CRC) 0 - No corrosion stress
- Pilot medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Electrical connection Form C Without PE conductor
- Pneumatic connection 1 Sub-base, size 18 mm as per ISO 15407-1
- Pilot interface as per ISO 15218
- Operating pressure 2 bar ... 10 bar
- Standard nominal flow rate 400 l/min
- Reset method Pneumatic spring
- Type code VSVA
- Manual override Non-detenting
- Pilot pressure 3 bar ... 10 bar
- Switching time off 21 ms
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Temperature of medium -5 °C ... 50 °C
- Max. tightening torque for valve mounting 1 Nm
- Auxiliary pilot air port 14 Sub-base, size 18 mm as per ISO 15407-1
- Pneumatic connection 4 Sub-base, size 18 mm as per ISO 15407-1
- Seals material HNBR NBR
- Pilot pressure MPa 0.3 MPa ... 1 MPa
- Signal status display LED
- Symbol 00991818
- On switching time 13 ms
- Vibration resistance Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
- Pilot exhaust air port 82/84 Not ducted as per standard Ducted
- Pneumatic connection 2 Sub-base, size 18 mm as per ISO 15407-1
- Pneumatic connection 5 Sub-base, size 18 mm as per ISO 15407-1
- Material of screws Steel Galvanized
- Lap Overlap
- Pneumatic working port Sub-base, size 18 mm as per ISO 15407-1 G1/8
- Degree of protection IP65 NEMA 4
- Sealing principle Soft
- Conforms to standard ISO 15407-1 VDMA 24563
- Flow direction Non-reversible
- Flow rate of pneumatic valve on individual sub-base 450 l/min
- Duty cycle 100%
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Relative air humidity 0 - 90 %
- Product weight 174 g
- Type of mounting On sub-base
- Housing material Die-cast aluminum
- Valve function 2x3/2, open/closed, monostable
- Actuation type Electrical
- Operating voltage 12V DC
- Exhaust air function With flow control option
- Pilot air supply port External
- Optimized flow rate of pneumatic valve pneumatically concatenated flow 400 l/min
- Permissible voltage fluctuations -15 % / +10 %
- Shock resistance Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
- Noise level 85 dB(A)
- Ambient temperature -5 °C ... 50 °C
- Auxiliary pilot air port 12 Sub-base, size 18 mm as per ISO 15407-1
- Pneumatic connection 3 Sub-base, size 18 mm as per ISO 15407-1
- Note on materials RoHS-compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
