AB7843-F HMS Networks Industrial Automation Components

AB7843-F on Powermatic Associates
HMS Networks

Part#:AB7843-F

Manufacturer:HMS Networks

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Anybus X-gateway – PROFIBUS Slave – PROFIBUS Slave

Product Details

  • Primary brand
    eWON by HMS Networks
  • Customs Tariff Number
    8517620090
  • Manufacturer description
    Anybus X-Gateways - Network 1 PROFIBUS DP-V0 Slave / Network 2 PROFIBUS DP-V0 Slave
  • Net Width (ERP) (mm)
    44 mm
  • Current Consumption Max value at Vcc nom (mA)
    400mA @ 24V DC
  • Storage Temperature °C Min
    -40 °C
  • Environment
    EN 61000-6-4, EN 55016-2-3 Class A, EN 55022 Class A, EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
  • DIP & Rotary Switches
    2x Rotary Address Node
  • PROFIBUS Configuration File
    GSD available
  • Current Consumption Type Value at Vcc Nom (mA)
    200mA @ 24V DC
  • Operating Temperature °C Min
    -25 °C
  • FCC
    No
  • Connectors / Input / Output
    1x D-sub 9-pin female PROFIBUS connector, USB-B Config port
  • HS Code
    8517620000
  • Input Voltage (V)
    24V DC (-20% to +20%)
  • Net Depth (ERP) (mm)
    114 mm
  • CE
    Yes
  • Waste Certification (WEEE)
    Yes
  • PROFIBUS Mode
    Slave
  • Net Height (ERP) (mm)
    127 mm
  • UL
    Yes
  • Recycle / Disposal
    TRUE
  • PROFIBUS Output Data Size
    244 bytes (344 max tot in+out)
  • Net Weight (ERP) (g)
    400 g
  • Housing Materials
    Aluminum, Plastic
  • UL File Number
    E214107: Ord.Loc UL508, CSA C22.2 NO. 142
  • Country of Origin
    Sweden
  • PROFIBUS Input Data Size
    244 bytes (344 max tot in+out)
  • Short Circuit Protection
    Yes
  • Storage Temperature °C Max
    85 °C
  • Contains Battery
    No
  • Dual Usage (ERP)
    No
  • Power Connector
    2-pin, 5.08 Phoenix plug connector
  • Reverse Polarity Protection
    Yes
  • RoHS Compliant
    Yes
  • PROFIBUS Device Address
    0-125
  • Isolation
    TRUE
  • PROFIBUS Supported Functionality
    PROFIBUS-DP/DPV1 Slave functionality according to extensions of EN 50170; Acyclic Communication (DP-V1, Class 1 & 2); Acyclic User Parameter data / Diagnostics length - up to 237 bytes; Sync; Freeze; Watchdog
  • Packaging Material
    Cardboard
  • WEEE Category
    IT and telecommunications equipment
  • Export Control Classification Number (ECCN) (ERP)
    5A991.b.3
  • Mounting
    DIN-rail (EN 50022 standard)
  • Operating Temperature °C Max
    65 °C
  • EMC
    Yes
  • Protection Class IP
    IP20
  • PROFIBUS Baud Rate
    9600 bit/s - 12 Mbit/s

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

About the product

Anybus by HMS Networks AB7843-F is a gateway within the X-gateway series designed for protocol translation. It features a PROFIBUS slave design and supports installation in both vertical and flat positions. This model offers galvanic isolation on both BUS/Ethernet sides and allows I/O configuration via a USB port using Anybus Configuration Manager software. It is equipped with 4 node address switches (x10 / x1) and 10 LED indicators for fieldbus, sub-network, and device status monitoring. The AB7843-F operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. Its housing is made from aluminium and plastic, ensuring durability while maintaining a lightweight design. Connection options include 2 x 9-pin D-sub female connectors for PROFIBUS, 1 x 2-poles 5.08mm plug-in screw connector for power (X3), and 1 x USB connector (X4). It offers an IP20 and NEMA 1 degree of protection and is suitable for DIN rail mounting. The communication protocol supported is PROFIBUS, with a speed of up to 12Mbit/s. The AB7843-F is designed to operate in ambient air temperatures ranging from -25 to +65 °C and can be stored in temperatures from -40 to +85 °C. Its current consumption is 400mA (max) and 200mA (typical) at 24Vdc. The device is also designed to withstand 5-95% relative humidity (RH; non-condensing).
