Part#:AB7954-F

Manufacturer:HMS Networks

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Anybus X-gateway – CC-Link IE Field Slave - PROFINET-IO Device

Product Details

  • Customs Tariff Number
    8517620090
  • Manufacturer description
    Anybus X-Gateways - Network 1 CC-Link IE Field Network Slave / Network 2 PROFINET I/O Slave
  • Primary brand
    eWON by HMS Networks
  • Input Voltage (V)
    24V DC (-20% to +20%)
  • Operating Temperature °C Max
    65 °C
  • Recycle / Disposal
    TRUE
  • CC-Link IE Field Output Data Size
    512 bytes
  • PROFINET Input Data Size
    512 bytes
  • Current Consumption Max value at Vcc nom (mA)
    400mA @ 24V DC
  • Short Circuit Protection
    Yes
  • EMC
    Yes
  • Contains Battery
    No
  • Current Consumption Type Value at Vcc Nom (mA)
    200mA @ 24V DC
  • Housing Materials
    Aluminum, Plastic
  • Environment
    EN 61000-6-4, EN 55016-2-3 Class A, EN 55022 Class A, EN 61000-6-2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
  • Dual Usage (ERP)
    No
  • PROFINET Bandwidth
    10/100Mbit full/half duplex down to 1ms
  • Mounting
    DIN-rail (EN 50022 standard)
  • Operating Temperature °C Min
    -25 °C
  • FCC
    No
  • Export Control Classification Number (ECCN) (ERP)
    5A991.b.1
  • PROFINET Configuration File
    GSDML available
  • Net Weight (ERP) (g)
    400 g
  • CE
    Yes
  • RoHS Compliant
    Yes
  • CC-Link IE Field Bandwith
    1 Gbit/s fixed
  • PROFINET Output Data Size
    512 bytes
  • Net Depth (ERP) (mm)
    114 mm
  • Packaging Material
    Cardboard
  • Protection Class IP
    IP20
  • Connectors / Input / Output
    2x RJ45, 2x RJ45, USB-B Config port
  • CC-Link IE Field Mode
    Slave
  • Net Width (ERP) (mm)
    44 mm
  • UL File Number
    E214107: Ord.Loc UL508, CSA C22.2 NO. 142
  • Country of Origin
    Sweden
  • CC-Link IE Field Supported Functionality
    CC-Link IE Field Network Intelligent Device Station
  • Reverse Polarity Protection
    Yes
  • Storage Temperature °C Min
    -40 °C
  • WEEE Category
    IT and telecommunications equipment
  • CC-Link IE Field Input Data Size
    512 bytes
  • PROFINET Supported Functionality
    Soft Real-Time (RT); Max 64 slots / 1 sub-slot; DCP support; Acyclic Data exchange
  • Isolation
    TRUE
  • Net Height (ERP) (mm)
    127 mm
  • UL
    Yes
  • DIP & Rotary Switches
    1x 8-dip switches for Station Number
  • PROFINET Mode
    Slave
  • Storage Temperature °C Max
    85 °C
  • Waste Certification (WEEE)
    Yes
  • HS Code
    8517620000
  • Power Connector
    2-pin, 5.08 Phoenix plug connector

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

About the product

Anybus by HMS Networks AB7954-F is a gateway designed for protocol translation within the X-gateway series. It supports installation in both vertical and flat positions and features galvanic isolation on both BUS and Ethernet sides. The I/O configuration is manageable via USB port using Anybus Configuration Manager software. This model integrates a CC-Link IE Field slave and a PROFINET-IO device, equipped with 8 configuration switches and 10 LED indicators for various status indications. It operates on a supply voltage of 19.2-28.8Vdc, with a nominal 24Vdc, and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability. Connection options include 2 x RJ45 CC-Link IE Field connectors, 1 x RJ45 connector for 100Mbit/s PROFINET (full duplex), 1 x 2-poles 5.08mm plug-in screw connector for power, and 1 x USB connector for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The communication protocols supported are CC-Link and PROFINET IO. It can operate in ambient air temperatures ranging from -25 to +65 °C, with a current consumption of 400mA (max) and 200mA (typical). Storage temperature tolerance ranges from -40 to +85 °C. The speed capabilities are 1Gbit/s for CC-Link IE Field and 100Mbit/s for PROFINET. It is designed to operate in environments with 5-95% relative humidity (non-condensing).
