8910DP22V02Y181Y248 Schneider Electric Electronic Components

8910DP22V02Y181Y248 on Powermatic Associates
Schneider Electric

Part#:8910DP22V02Y181Y248

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Contactor, Definite Purpose, 25A, 2 pole, 110/120 VAC 50/60 Hz coil, open, with cover, bulk packaged

Product Details

  • Number Of Poles
    2P
  • Range Of Product
    DP
  • Line Rated Current
    20 A
  • [Ue] Rated Operational Voltage
    600 V AC
  • Type Of Packing
    Bulk
  • Provided Equipment
    Terminal cover
  • Phase
    1 phase
  • Product Or Component Type
    Definite Purpose Contactor
  • Pole Contact Composition
    2 NO
  • Maximum Horse Power Rating
    2 hp 115 V AC, 1 phase 3 hp 230 V AC, 1 phase
  • [Uc] Control Circuit Voltage
    120 V AC 60 Hz 110 V AC 50 Hz
  • Electrical Connection
    Quick connect terminals Binder head
  • Locked Rotor Rated Current
    125 A 460 V AC 100 A 575 V AC 150 A 277 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 8910DP22V02Y181Y248 on Powermatic Associates is $66.88. Order now.
