GB2CB12 Schneider Electric Industrial Automation Components

Product Details

• Tightening Torque
  10.62 lbf.in (1.2 N.m) connector
• [Uimp] Rated Impulse Withstand Voltage
  4 kV IEC 60947-2
• 9 Mm Pitches
  2
• Range
  TeSys
• Network Type
  AC/DC
• Magnetic Tripping Current
  83 A
• Mechanical Durability
  8000 cycles
• Depth
  2.64 in (67 mm)
• Product Name
  TeSys GB2
• Control Type
  Toggle
• Product Or Component Type
  Circuit breaker
• Quantity Per Set
  Set of 6
• Device Application
  Control
• Mounting Mode
  By clips
• Poles Description
  1P
• Line Rated Current
  6 A
• Electrical Durability
  8000 cycles
• Height
  2.91 in (74 mm)
• Device Short Name
  GB2
• Trip Unit Technology
  Thermal-magnetic
Power Dissipation Per Pole
2 W
Network Frequency
50/60 Hz IEC 60947-2
Width
0.59 in (15 mm)
Mechanical Robustness
Shocks 22 Gn for 20 ms IEC 60068-2-27 Vibrations 5 Gn, 5...110 Hz IEC 60068-2-6
[Ics] Rated Service Short-Circuit Breaking Capacity
75 % 110 V AC 50/60 Hz IEC 60947-2 75 % 230/240 V AC 50/60 Hz IEC 60947-2
Mounting Support
Rail Plate
Mounting Position
Vertical Horizontal
Utilisation Category
Category A conforming to IEC 60947-2 DC-12 IEC 60947-5-1 DC-13 IEC 60947-5-1
[Ue] Rated Operational Voltage
250 V AC 50/60 Hz IEC 60947-2 277 V AC 60 Hz CSA C22.2 No 235 277 V AC 60 Hz UL 1077 48 V DC
Breaking Capacity
3 kA Icu 110 V AC 50/60 Hz IEC 60947-2 1.5 kA Icu 230/240 V AC 50/60 Hz IEC 60947-2 1.5 kA Icu 24 V DC IEC 60947-2 1 kA Icu 48 V DC IEC 60947-2
Connections - Terminals
connector 1 0.00…0.01 in² (0.75…6 mm²)solid without cable end connector 2 0.00…0.01 in² (0.75…4 mm²)solid without cable end connector 1 0.00…0.01 in² (0.75…4 mm²)flexible with cable end connector 2 0.00…0.00 in² (0.75…2.5 mm²)flexible wi
