H324NVW Schneider Electric Electronic Components

H324NVW on Powermatic Associates
Schneider Electric

Part#:H324NVW

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

SWS FUSIBLE HD 240V 3P 200A NEMA 1 VW

Product Details

  • Current Rating
    200 A
  • Net Weight
    55.49 lb(US) (25.17 kg)
  • Factory Installed Neutral
    Neutral (factory installed)
  • Mounting Type
    Surface
  • Product
    Single Throw Safety Switch
  • Tightening Torque
    275 lbf.in (31.07 N.m) 0.02…0.20 in² (13.3…127 mm²) (AWG 6...250 kcmil)
  • Device Application
    Heavy application
  • Wire Size
    AWG 6...250 kcmil copper or aluminium
  • Depth
    8.25 in (209.55 mm)
  • Duty Rating
    Heavy duty
  • Wiring Configuration
    4-wire (3PH + G)
  • Disconnect Type
    Fusible disconnect
  • Number Of Poles
    3
  • Enclosure Rating
    NEMA 1 steel
  • Width
    17.13 in (435.10 mm)
  • Phase
    3 phase
  • Height
    29 in (736.60 mm)
  • Voltage Rating
    250 V DC 240 V AC
  • Maximum Horse Power Rating
    15 hp 240 V at AC 50-60 Hz for 1 phase conforming to NEC 240.6 25 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 240.6 60 hp 240 V at AC 50-60 Hz for 3 phase conforming to NEC 430.52 40 hp 250 V at DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
