Product description

Square D by Schneider Electric HDL36015T is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HDL sub-range, featuring a removable/interchangeable trip unit PowerPacT H-Frame 150 TMD 3P 15A 600Vac/250Vdc 14kA with lugs on both load and line sides. This 3-pole circuit breaker offers thermal protection for overload scenarios and magnetic protection for short-circuit conditions. It has a rated current of 15A, with a rated insulation voltage of 750 V and operates at a rated voltage of 600Vac 600Y/347Vac for AC circuits and 250Vdc for DC circuits. The unit is designed for individual mounting on a plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. It provides an IP40 degree of protection and features a manual toggle operating mode. Protection settings include over-current fixed at 15A, short-circuit hold current fixed at 350A, and short-circuit trip current fixed at 750A. The rated operating voltage is 690 V, with a rated impulse voltage of 8 kV. The trip current rating is 15 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies by voltage, including 25kA at 240Vac, 18kA at 480Vac and 480Y/277Vac, 14kA at 600Vac and 600Y/347Vac for UL489 standards, and 20kA at 250Vdc. The trip unit type is thermal-magnetic (fixed) without a display, and it falls under utilisation category A.

Product Details

  • Product Or Component Type
    Circuit breaker
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Range Of Product
    PowerPact H
  • Height
    6.4 in (162.56 mm)
  • Continuous Current Rating
    80 %
  • Mounting Mode
    Unit mount
  • Line Rated Current
    15 A
  • Breaking Capacity Code
    D
  • Depth
    4.36 in (110.74 mm)
  • Magnetic Tripping Current
    750 A
  • Number Of Poles
    3P
  • Magnetic Hold Current
    350 A
  • Width
    4.12 in (104.65 mm)
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HDL36015T on Powermatic Associates is $1,088.00. Order now.
