Part#:HLL26025

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - HLL26025

Product Details

  • Mounting Mode
    Unit mount
  • Width
    4.12 in (104.65 mm)
  • Depth
    4.36 in (110.74 mm)
  • Breaking Capacity Code
    L
  • Magnetic Tripping Current
    750 A
  • Height
    6.4 in (162.56 mm)
  • Range Of Product
    PowerPact H
  • Product Or Component Type
    Circuit breaker
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Continuous Current Rating
    80 %
  • Magnetic Hold Current
    350 A
  • Line Rated Current
    25 A
  • Number Of Poles
    2P
  • UPC:
    60648628283
  • Shipping Length:
    7.00 In.
  • TS PIK:
    120072010
  • Shipping Weight:
    3.50 lbs.
  • Shipping Width:
    5.00 In.
  • Shipping Height:
    6.00 In.
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HLL26025 on Powermatic Associates is $3,546.00. Order now.
