HLL36020C Schneider Electric Electronic Components

HLL36020C on Powermatic Associates
Schneider Electric

Part#:HLL36020C

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HLL36020C is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HLL sub-range, featuring a PowerPact H-Frame 150 TMD 3P 20A 600Vac/500Vdc 50kA design. It is equipped with lugs on both load and line sides for connection, operates on three poles (3P), and offers thermal protection for overload and magnetic protection for short-circuits. The rated current is 20A, with a rated insulation voltage (Ui) of 750 V, and it supports a rated voltage (AC) of 600Vac 600Y/347Vac. This unit is designed for individual unit mount on plate, has a net height of 163 mm, a net width of 104 mm, and a net depth of 86 mm. It features an IP40 degree of protection, a toggle (manual) operating mode, and fixed protection settings for over-current at 20A and short-circuit hold and trip currents at 350A and 750A, respectively. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 20 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies across voltages, with a maximum of 125kA at 240Vac and a minimum of 20kA at 250Vdc, according to UL489 standards. The trip unit type is thermal-magnetic (fixed) without a display, and it falls under utilisation category A.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Width
    4.12 in (104.65 mm)
  • Depth
    4.36 in (110.74 mm)
  • Height
    6.4 in (162.56 mm)
  • Continuous Current Rating
    100 %
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Magnetic Hold Current
    350 A
  • Magnetic Tripping Current
    750 A
  • Breaking Capacity Code
    L
  • Mounting Mode
    Unit mount
  • Number Of Poles
    3P
  • Product Or Component Type
    Circuit breaker
  • Range Of Product
    PowerPact H
  • Line Rated Current
    20 A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HLL36020C on Powermatic Associates is $7,692.75. Order now.

HLL36020C Related Documents

Product Datasheet-1631040875554.pdf
