QOU2353100 Schneider Electric Industrial Automation Components

QOU2353100 on Powermatic Associates
Schneider Electric

Part#:QOU2353100

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOU2353100 is a miniature circuit breaker (MCB) designed for unit mount installation. It features a rated current of 35A and accommodates slotted box lugs connections on both the load and line side. This MCB is compatible with a cross-section of 14-2AWG for one aluminum or copper cable and is equipped with two poles. It offers a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The rated voltage for AC operation is 120V to 240V, and for DC operation, it is 48Vdc. The terminals are of the box lugs type, facilitating secure and reliable connections.

Product Details

  • AWG Gauge
    AWG 14...AWG 2 aluminium/copper
  • Depth
    2.95 in (74.93 mm)
  • Range Of Product
    QOU
  • Circuit Breaker Application
    HACR and Switching Duty rated
  • Width
    1.5 in (38.10 mm)
  • Tightening Torque
    45 lbf.in (5.08 N.m) (AWG 14...AWG 2)
  • Mounting Mode
    Unit mount
  • Circuit Breaker Type
    Standard
  • Product Or Component Type
    Miniature circuit-breaker
  • Line Rated Current
    35 A
  • Height
    4.05 in (102.87 mm)
  • Electrical Connection
    Slotted box lugs, line side Slotted box lugs, load side
  • [Ue] Rated Operational Voltage
    120/240 V AC 120 V AC 48 V DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOU2353100 on Powermatic Associates is $105.00. Order now.

QOU2353100 Related Documents

Catalog-1631030789378.pdfInstruction Sheet-1631030789380.pdfProduct Datasheet-1631030789382.pdf
