Part#:QOUR3203100

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOUR3203100 is a miniature circuit breaker (MCB) designed for unit mount installation. It features a 3-pole configuration and is rated for a current of 20A. This MCB is equipped with slotted box lugs connections for both load and line sides, accommodating a cross-section of 14-2AWG for 1 cable Al/Cu. It operates at a rated voltage of 48Vdc and 120V/240V AC, with a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The terminals are of the box lugs type.

Product Details

  • Line Rated Current
    20 A
  • Tightening Torque
    45 lbf.in (5.08 N.m) (AWG 14...AWG 2)
  • AWG Gauge
    AWG 14...AWG 2 aluminium/copper
  • Product Or Component Type
    Miniature circuit-breaker
  • Circuit Breaker Type
    Standard
  • Width
    2.25 in (57.15 mm)
  • Range Of Product
    QOU
  • Depth
    2.95 in (74.93 mm)
  • Mounting Mode
    Unit mount
  • Circuit Breaker Application
    HACR and Switching Duty rated
  • Height
    4.05 in (102.87 mm)
  • Electrical Connection
    Slotted box lugs, line side Slotted box lugs, load side
  • [Ue] Rated Operational Voltage
    120/240 V AC 240 V AC 120 V AC 48 V DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOUR3203100 on Powermatic Associates is $342.00. Order now.
