REI-E-113T10C-2B5000-H1181 Turck Industrial Automation Components
Part#:REI-E-113T10C-2B5000-H1181
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Discontinued
Product description
REI-E-113T10C-2B5000-H1181 Turck - REI-E-113T10C-2B5000-H1181 Incremental Encoder, Efficiency Line
Product Details
- Technology Optical
- Ambient temperature -20…+70 °C
- Flange type Clamping flange
- Protection class IP64
- Output function Push-Pull/HTL, with inverted signals
- Shaft diameter D [mm] 10 mm
- Encoder line Efficiency-Line
- Protection class shaft IP64
- Shaft Type Solid shaft
- Housing material Die-cast zinc
- Output type Incremental
- Operating voltage 10…30 VDC
- Electrical connection Connector, M12 × 1
- Flange diameter Ø 58 mm
- Resolution, incremental 5000 ppr
- Ambient Temperature -20 degrees celsius, 70 degrees celsius
- Country of Origin India
- Weight 382 grams
- Operating Voltage 10 volts, 30 volts
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Incremental Encoder, Efficiency Line, Resolution, incremental 5000 ppr, Clamping flange, Ø 58 mm, Solid shaft, Ø 10 mm × 20 mm, Optical measuring principle, Shaft material: stainless steel, Protection class IP64 on housing and shaft side, ‐20…+70 °C, Max. 4500 rpm (continuous operation 3000 rpm), 10…30 VDC, Male connector, M12 x 1, 8-pole, Push-pull, with inverted signals, Pulse frequency max. 300 kHz, 5000 pulses per revolution
