K50FLGRYPQ Banner Pick-to-Light Sensors
Part#:K50FLGRYPQ
Alt. Part#:83435
Manufacturer:Banner
Category:Pick-to-Light Sensors
Product Lifecycle:Active
Product description
K50 Series EZ-LIGHT: 3-Color General Purpose Flat Pack Indicator; Voltage: 18-30 V dc; Environmental Rating: IP67; IP69K; Input: PNP; Colors: Green Red Yellow; 4-pin M12 Integral QD
Product Details
- Weight 137.3476576 g
- Country Of Origin MX
- Primary Housing Material Polycarbonate
- Animation Option 1 Solid On
- Max Input Response Time (ms) 1
- Max Op. Temperature (°C) 50
- Pro-Editor Compatible (Discrete) No
- Number of Colors / Segments 3
- Quick Disconnect Type M12 (Euro)
- Supply Voltage 18-30 V dc
- Feature: Hazardous Area No
- Power DC
- Connection Integral QD
- Input Type PNP
- Multi-Color Device Single Color On
- Indication Yes
- Color Option 2 Red
- Physical Dimensions (LxWxH or DxH mm) 50.0 x 76.0 x 44.6
- Feature: Chemical Resistant No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Option 1 Green
- IO Link No
- Housing Style Flat Mount - Dome Window
- Color Technology Standard LED
- Number of Input Pins/Conductors 4
- Power Source DC
- Color Option 3 Yellow
- Min Op. Temperature (°C) -40
- Feature: Washdown Rated Yes
- Product Size (mm) 50
- Cable Length (m) 2
- Environmental Rating IP67; IP69
- Primary Window Material Polycarbonate Diffused
- Mounting Thread No Thread
- Wireless No
- Modbus RTU No
- Max Current Color (mA) 40
- Feature: Audible No
- Primary Housing Color Black
- Max Op. Relative Humidity Non-Condensing (%) 95% @ 50°C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of K50FLGRYPQ on Powermatic Associates is $106.00. Order now.
About the product
Banner Engineering K50FLGRYPQ is a pilot light from the EZ-LIGHT Flat-mount series designed for surface or wall mounting. This part features a flat-pack LED pilot light indicator with a 3-color G/R/Y color pattern LED illumination housed in a black polycarbonate base with a dome window on a flat-pack body. The dome has a diameter of 50mm / 2 inches, and the window material is also polycarbonate (PC), ensuring durability. It is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The K50FLGRYPQ operates on a supply voltage of 18Vdc to 30Vdc, with 24Vdc nominal, and has a current consumption of 40mA. It includes 3 x digital inputs (18-30Vdc; NPN) for color control. This part is designed to operate in ambient air temperatures ranging from -40°C to +50°C and offers a high degree of protection with ratings of IP67 and IP69K, making it suitable for challenging environments.
