SLLR23-910-S Banner Safety Light Curtains
Part#:SLLR23-910-S
Alt. Part#:809026
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
EZ-SCREEN LS, Receiver; Resolution: 23 mm; Range: 12 m (40 ft); Defined Area: 910 mm (35.8 in); Housing: Black; Connection: Removable Disconnect (RD); Mounting Hardware and Cable/M12 Pigtail Ordered Separately
Product Details
- Weight 2177.2416 g
- Country Of Origin MX
- Defined Area Height (mm) 910
- Effective Aperture Angle Type 4 Per IEC 61496-2
- Operating Temperature -20 to +55 deg. C; RH 95%
- PL Rating Ple
- Resolution (mm) 23
- Auxiliary Output No
- Feature: End-to-End Sensing Yes
- Vibration 10-55 Hz at 0.35 mm
- Feature: Integral Muting No
- Fault Output Yes
- Housing Material Aluminum; Zinc; Acrylic
- OSSD Rating 24 V dc at 0.5 A each
- Test Input No
- Short Protection Yes
- Feature: ESD Safe No
- Overall Length (mm) 914
- Operating Voltage 24 V dc +/- 15%
- Safety Level Type 4
- Operating Distance (m) 0.1 - 12
- Shock 10g at 16ms (6000 cycles)
- Primary Housing Material Aluminum
- External Monitoring Device 1 Channel
- Housing Finish Yellow Polyester
- Recovery Time 67 / 225
- Trip/Latch Output Trip
- Electrical Safety Class III
- System Type Receiver
- Supply Current 89 mA Typical
- Connector Type Removable Disconnect
- IP Rating IP65; IP67
- Reduced Resolution No
- Fixed Blanking No
- SIL Rating SIL3; CL3
- Dimensions WxD (mm) 36 x 45
- Scan Code Selectable
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SLLR23-910-S on Powermatic Associates is $1,272.00. Order now.
About the product
Banner Engineering SLLR23-910-S, part of the LS-S series type 4 safety light curtains, is a safety light curtain receiver designed with an aluminium housing, acrylic lens, and zinc end caps. It features an integral removable disconnect (RD) for its connection type and is encased in a yellow housing. The device offers a protective height of 910mm and operates on a 24Vdc supply voltage. It is engineered to function within an ambient air temperature range of -20 to +55°C and is rated with a degree of protection of IP65 and IP67, ensuring its operation in various environmental conditions. The SLLR23-910-S has dimensions of 36mm in width, 914mm in height, and 45mm in depth. It is designed with a 23mm beam spacing/pitch, providing a resolution suitable for hand detection. This model includes 2 x digital outputs (24Vdc; 500mA; sourcing; redundant OSSD solid-state outputs), supports a sensing distance from 10cm to 12m, and has a response time of 15.9ms / 0.0159 s.
SLLR23-910-S Related Documents
Similar products from: Banner Safety Light Curtains
Manufacturer warranty
SLLR23-910-S Banner
$1,272.00
Your price can be lower.
Log in or Create account to check your discount
Select Qty:
$1,272.00
$1,272.00 each
