8502SCO2V07 Schneider Electric Electronic Components

8502SCO2V07 on Powermatic Associates
Schneider Electric

Part#:8502SCO2V07

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

NEMA Contactor, Type S, nonreversing, Size 1, 27A, 10 HP at 575 VAC, 3 phase, up to 100 kA, 3 pole, 600 VAC coil, open

Product Details

  • Other Equipment
    Fuse not supplied
  • Terminal Type
    Screw clamp terminals
  • Maximum Voltage Rating
    600 V AC
  • Rated Current
    27 A
  • Control Units
    No control units
  • Product Range
    8502S
  • Pilot Light
    No indicator
  • Depth
    4.22 in (107.19 mm)
  • Contactor Type
    Non-reversing
  • Control Circuit Type
    Common control circuit
  • Width
    3.22 in (81.79 mm)
  • Number Of Poles
    3P
  • Product Type
    Contactor
  • Height
    4.34 in (110.24 mm)
  • NEMA Size
    1
  • Auxiliary Contacts
    Without
  • Phase
    3 phase
  • Coil Voltage
    600 V AC 60 Hz 550 V AC 50 Hz
  • Horsepower Rating
    7.5 HP 200 V AC 7.5 HP 230 V AC 10 HP 460 V AC 10 HP 575 V AC
  • SCCR
    Circuit-breaker 70 A maximum, SCCR: 100 kA at 480 V AC Fuse J 60 A maximum, SCCR: 100 kA at 600 V AC Fuse T 60 A maximum, SCCR: 100 kA at 600 V AC Fuse RK1 60 A maximum, SCCR: 100 kA at 600 V AC Fuse RK5 60 A maximum, SCCR: 100 kA at 6

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 8502SCO2V07 on Powermatic Associates is $485.00. Order now.

8502SCO2V07 Related Documents

Product Datasheet-1631031273160.pdfCatalog-1631031273177.pdfInstruction Sheet-1631031273174.pdf
