Part#:PGP36100U31A

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

MOLDED CASE CIRCUIT BREAKER 600V 1000A

Product Details

  • Poles Description
    3P
  • Current Sensor Rating Range
    1000 A
  • Product Or Component Type
    Circuit breaker
  • Range
    PowerPact P
  • Rated Current
    1000 A
  • Continuous Current Rating
    80 %
  • Height
    16.16 in (410.46 mm)
  • Trip Unit Technology
    Electronic, standard, Micrologic 3.0, LI
  • Mounting Location
    Bolt-on
  • Device Short Name
    A
  • Circuit Breaker Rating Code
    G
  • Rated Operatioal Voltage
    600 V AC
  • Depth
    8.05 in (204.47 mm)
  • Module Type
    P-Frame
  • AWG Gauge
    AWG 3/0...500 kcmil aluminium/copper)4
  • Mounting Mode
    Unit mount
  • Width
    8.27 in (210.06 mm)
  • Tightening Torque
    442.54 lbf.in (50 N.m) 0.15…0.37 in² (95…240 mm²) (AWG 3/0...500 kcmil) 8.85…11.51 lbf.in (1.0…1.3 N.m)
  • Electrical Connection
    Lugs line Terminal nut load
  • Certifications
    UL Listed CSA IEC
  • Breaking Capacity
    65 kA 240 V AC 35 kA 480 V AC 18 kA 600 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PGP36100U31A on Powermatic Associates is $19,836.00. Order now.
