RE22R2QEMT Schneider Electric Industrial Automation Components

RE22R2QEMT on Powermatic Associates
Schneider Electric

Part#:RE22R2QEMT

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric RE22R2QEMT is an analog timer designed for modular installation on a DIN rail, featuring a single function with a star-delta timer mechanism. It includes 1 NC + 1 NO outputs with a split common, controlled via a rotary knob and a diagnostic button. The timer has a recovery time of 120ms upon de-energisation and a power-on delay of 100ms. It supports a rated current of 8 A and falls under the RE22 sub-range. The housing is made from self-extinguishing material, offering a degree of protection of IP40 for the housing, IP20 for the terminals, and IP50 for the front panel. The power consumption at 380Vac is 15 VA, and it features DPDT (Double Pole Double Throw) - 2C/O contacts type. The rated impulse voltage is 5 kV, and it operates on a supply voltage of 380-415 V AC, with a minimum of 323 V. The display includes a green LED backlight for dial pointer indication, along with yellow LEDs for various status indications such as output relay energised, timing in progress, and output relay de-energised. It offers electrical durability of 100,000 operations at 250vac/24Vdc and 10,000,000 operations without load. The time delay range is 1s - 300h, and it can operate within a temperature range of -20°C to +60°C.

Product Details

  • Status LED
    Green LED backlight steady)dial pointer indication Yellow LED steady)output relay energised Yellow LED fast flashing)timing in progress and output relay de-energised Yellow LED slow flashing)timing in progress and output relay energised
  • Connections - Terminals
    Screw terminals, 1 x 0.5...1 x 3.3 mm² AWG 20...AWG 12) solid without cable end Screw terminals, 2 x 0.5...2 x 2.5 mm² AWG 20...AWG 14) solid without cable end Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 24...AWG 14) flexible with cable end
  • Control Type
    Rotary knob Diagnostic button
  • Electrical Durability
    100000 cycles, 8 A at 250 V, AC-1 100000 cycles, 2 A at 24 V, DC-1
  • Mounting Support
    35 mm DIN rail conforming to EN/IEC 60715
  • Net Weight
    0.20 lb(US) (0.09 kg)
  • Width
    0.89 in (22.5 mm)
  • Mounting Position
    Any position
  • Safety Reliability Data
    B10d = 250000 MTTFd = 273.9 years
  • Overvoltage Category
    III IEC 60664-1
  • Rated Impulse Withstand Voltage
    5 kV 1.2…50 µs IEC 60664-1
  • Creepage Distance
    4 kV/3 IEC 60664-1
  • Mechanical Durability
    10000000 cycles
  • Power On Delay
    100 ms
  • Maximum Switching Voltage
    250 V AC
  • Maximum Switching Current
    8 A
  • Minimum Switching Current
    10 mA 5 V DC
  • Switching Capacity In VA
    2000 VA
  • Immunity To Microbreaks
    10 ms
  • Power Consumption In VA
    15 VA 380 V AC
  • Recovery Time
    120 ms on de-energisation
  • Setting Accuracy Of Time Delay
    +/- 10 % of full scale 25 °C IEC 61812-1
  • Temperature Drift
    +/- 0.05 %/°C
  • Insulation Resistance
    100 MOhm 500 V DC IEC 60664-1
  • Repeat Accuracy
    +/- 0.5 % IEC 61812-1
  • Voltage Drift
    +/- 0.2 %/V
  • Housing Material
    Self-extinguishing
  • Supply Frequency
    50...60 Hz +/- 5 %
  • Tightening Torque
    5.31…8.85 lbf.in (0.6…1 N.m) IEC 60947-1
  • Release Input Voltage
    <= 38 V
  • [Us] Rated Supply Voltage
    380...415 V AC 50/60 Hz
  • Voltage Range
    0.85...1.16 Us
  • Time Delay Range
    0.3...30 s
  • Time Delay Type
    Star-delta
  • Nominal Output Current
    8 A
  • Contacts Type And Composition
    2 C/O timed contact, cadmium free
  • Product Or Component Type
    Single function relay
  • Device Short Name
    RE22
  • Discrete Output Type
    Relay
  • Range Of Product
    Harmony Timer Relays

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of RE22R2QEMT on Powermatic Associates is $54.44. Order now.

RE22R2QEMT Related Documents

Instruction Sheet-1631031032755.pdfProduct Datasheet-1631031032753.pdfCatalog-1631031032748.pdf
