LS-534-0600-LIU22PN8X-H1151 Turck Industrial Automation Components
Part#:LS-534-0600-LIU22PN8X-H1151
Alt. Part#:100001865
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
LS-534-0600-LIU22PN8X-H1151 Turck - LS-534-0600-LIU22PN8X-H1151 Level Sensor, With Analog Output and 2 × Switching Outputs
Product Details
- Weight 1612 g
- RoHS Yes
- Country Of Origin DEU
- HTS Code 8536507000
- Measuring principle Guided microwave
- Electrical connection Connector, M12 × 1
- Output function NO/NC, PNP/NPN, analog output
- Communication protocol IO-Link
- Medium liquids
- Probe length (L) 600 mm
- Operating voltage 12…30 VDC
- Medium temperature -20…+100 °C
- Pressure resistance -1…10 bar
- Voltage output 0…10 V
- Ambient temperature -20…+60 °C
- Detection type medium contact
- Protection class IP67
- Process connection 3/4” NPT male thread
- Materials (contact with media) Stainless steel 1.4404 (AISI 316L), PTFE, FKM
- Current output 4…20 mA
- Housing material Plastic, PBT
- Weight 1612 grams
- Country of Origin Germany
- Operating Voltage 12 volts, 30 volts
- Ambient Temperature -20 degrees celsius, 60 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LS-534-0600-LIU22PN8X-H1151 on Powermatic Associates is $706.80. Order now.
About the product
Level Sensor, With Analog Output and 2 × Switching Outputs, , Multiple output signals: one system for both level detection and continuous level monitoring, Low maintenance and quick commissioning without calibration, High flexibility due to cutable probe, Compact, rotatable display housing ensures easy installation, Small inactive areas, ideal for small containers, Process temperature to 212 °F, Process pressure up to 145 psi, Coaxial tubes available for non-metallic tanks, IO-Link 1.1, , 12…30 VDC, 1 × analog output 4… 20 mA/0… 10 V (automatic switchover depending on load), 2 × PNP/IO-Link or PNP/NPN transistor outputs, each switchable, Process connection NPT 3/4 male thread, Probe length 600 mm, "
