LS-551-0300-LIU24PN8X-H1181 Turck Industrial Automation Components
Part#:LS-551-0300-LIU24PN8X-H1181
Alt. Part#:100001854
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
LS-551-0300-LIU24PN8X-H1181 Turck - LS-551-0300-LIU24PN8X-H1181 Level Sensor, With Analog Output and 4 × Switching Outputs
Product Details
- Weight 1100 g
- RoHS Yes
- Country Of Origin DEU
- HTS Code 8536507000
- Protection class IP67
- Measuring principle Guided microwave
- Medium temperature -20…+100 °C
- Communication protocol IO-Link
- Detection type medium contact
- Probe length (L) 300 mm
- Ambient temperature -20…+60 °C
- Operating voltage 12…30 VDC
- Materials (contact with media) Stainless steel 1.4404 (AISI 316L), PTFE, FKM
- Current output 4…20 mA
- Process connection G 3/4'' male thread
- Medium liquids
- Housing material Plastic, PBT
- Voltage output 0…10 V
- Electrical connection Connector, M12 × 1
- Output function NO/NC, PNP/NPN, analog output
- Pressure resistance -1…10 bar
- Country of Origin Germany
- Ambient Temperature -20 degrees celsius, 60 degrees celsius
- Weight 1100 grams
- Operating Voltage 12 volts, 30 volts
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LS-551-0300-LIU24PN8X-H1181 on Powermatic Associates is $841.10. Order now.
About the product
Level Sensor, With Analog Output and 4 × Switching Outputs, , Multiple output signals: one system for both level detection and continuous level monitoring, Low maintenance and quick commissioning without calibration, High flexibility due to cutable probe, Compact, rotatable display housing ensures easy installation, Small inactive areas, ideal for small containers, Process temperature to 212 °F, Process pressure up to 145 psi, Coaxial tubes available for non-metallic tanks, IO-Link 1.1, , 12…30 VDC, 1x analog output 4… 20 mA/0… 10 V (automatic switchover depending on load), 1x transistor output (PNP) or IO-Link, 3x transistor output (PNP/NPN switchable), Process connection G3/4 male thread, Probe length 300 mm, "
