K50BLGA120Q Banner Electronic Components

Product Details

• Indication
  Yes
• Cable Length (m)
  2
• Max Input Response Time (ms)
  0.5
• Feature: Washdown Rated
  Yes
• Multi-Color Device
  Single Color On
• IO Link
  No
• Mounting Thread
  M30 x 1.5
• Animation Option 1
  Solid On
• Physical Dimensions (LxWxH or DxH mm)
  50.0 x 60.0
• Modbus RTU
  No
• Housing Style
  Base Mount - Flat Window
• Supply Voltage
  85-130 V ac/75-120 V dc
• Min Op. Temperature (°C)
  -40
• Feature: Quick Disconnect
  Yes
• Power
  DC or AC
• Connection
  Integral QD
• Max Op. Relative Humidity Non-Condensing (%)
  90% @ 50°C
• Indication Intensity
  High Brightness & Daylight Visible
• Primary Housing Material
  Polycarbonate
• Max Current Color (mA)
  16
Environmental Rating
IP67; IP69
Feature: Audible
No
Power Source
DC or AC
Color Technology
Standard LED
NEMA Type and UL Type Rating
NEMA 4X, 13
Feature: Hazardous Area
No
Wireless
No
Color Input Control
Individual (One wire/color, same number of colors as input wires)
Number of Input Pins/Conductors
3
Primary Window Material
Polycarbonate Clear
Pro-Editor Compatible (Discrete)
No
Product Size (mm)
50
Color Option 1
Green
Primary Housing Color
Black
Number of Colors / Segments
1
Input Type
AC
Max Op. Temperature (°C)
50
Feature: Chemical Resistant
No
