Part#:QOB220VH35

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Mini circuit breaker, QO, 20A, 2 pole, 120/240 VAC, 22 kA, bolt on mount, 50 degrees C

Product Details

  • Depth
    2.91 in (73.91 mm)
  • Electrical Connection
    Pressure plate
  • Height
    3 in (76.20 mm)
  • Range
    QO
  • Circuit Breaker Type
    Standard
  • Number Of Panel Spaces
    2
  • Mounting Type
    Bolt-on
  • Number Of Poles
    2P
  • Product
    Miniature circuit-breaker
  • Width
    1.5 in (38.10 mm)
  • Ratings
    Not rated
  • Wire Size
    AWG 14...AWG 8 copper or aluminium
  • Current Rating
    20 A
  • Tightening Torque
    40.71 lbf.in (4.6 N.m)
  • Interrupt Rating
    22 kA 120/240 V AC 50/60 Hz 22 kA 240 V AC 50/60 Hz 22 kA 120 V AC 50/60 Hz
  • Voltage Rating
    120/240 V AC 240 V AC 120 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
