SLSP14-1350P88 Banner Electronic Components

Product Details

• Primary Housing Material
  Aluminum
• Operating Distance (m)
  0.1 - 6
• Auxiliary Output
  Yes
• Supply Current
  375 mA max.
• Feature: End-to-End Sensing
  No
• Recovery Time
  33-220 / 109-800
• Resolution (mm)
  14
• Dimensions WxD (mm)
  36 x 45.2
• low-profile
  No
• Fixed Blanking
  Yes
• Number of Pins (Receiver/Emitter)
  8
• Reduced Resolution
  Yes
• SIL Rating
  SIL3; CL3
• Electrical Safety Class
  III
• Vibration
  10-55 Hz at 0.35 mm
• Fault Output
  No
• OSSD Rating
  24 V dc at 0.5 A each
• Safety Level
  Type 4
• Effective Aperture Angle
  Type 4 Per IEC 61496-2
• Housing Finish
  Yellow Polyester
Operating Temperature
0 to +55 deg. C; RH 95%
Scan Code
Selectable
Response Time
43
System Type
Emitter/Receiver Pair
Trip/Latch Output
Selectable
Housing Material
Aluminum; Zinc; Acrylic
Test Input
No
Connector Type
M12 Pigtail (Yellow)
External Monitoring Device
1 or 2 Channel
IP Rating
IP65
Defined Area Height (mm)
1350
Overall Length (mm)
1420
Operating Voltage
24 V dc +/- 15%
PL Rating
Ple
Shock
10g at 16ms (6000 cycles)
Short Protection
Yes
Feature: Integral Muting
No
Feature: ESD Safe
No
