739-106 WAGO Industrial Automation Components
Part#:739-106
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
739-106 WAGO - PCB terminal block; 2.5 mm²; Pin spacing 5 mm; 6-pole; CAGE CLAMP®; 2,50 mm²; gray
Product Details
- Weight 7.021001847 g
- Country Of Origin Switzerland
- HTS Code 85369010000
- Actuator Operating Tool
- Package Type Box
- Contact Material Copper
- Width 1.181 inches, 30 millimeters
- Color Gray
- Strip Length 0.35 inches, 9 millimeters
- Conductor Size 14 american wire gauge, 2.5 millimeters
- Voltage 300 volts, 320 volts
- Current 20 amperes, 24 amperes
- Insulation Material Polyamide
- Depth 0.563 inches, 14.3 millimeters
- Height 0.748 inches, 19 millimeters
- Contact Type Tin
- Weight 7.021 grams
- Flammability Class V0
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 739-106 on Powermatic Associates is $2.45. Order now.
About the product
WAGO 739-106 is an automation part with a short circuit breaking rating and electrical data ratings per IEC/EN 60664-1, including a nominal voltage (III/3) of 320V, rated impulse voltage (III/3) of 4kV, rated voltage (III/2) of 320V, rated impulse voltage (III/2) of 4kV, nominal voltage (II/2) of 630V, rated surge voltage (II/2) of 4kV, and a rated current of 24A. It has UL 1059 approval with rated voltages of 300V and rated currents of 20A for Use Group B and 10A for Use Group D. CSA approvals include rated voltages of 300V and rated currents of 12A for Use Group B and 10A for Use Group D. The part features 6 connection points, a single connection type with CAGE CLAMP technology, and supports conductor sizes from 0.08 to 2.5mm2 / 28 to 14 AWG. It has a pole number of 6, pin spacing of 5mm, dimensions of 30mm in width, 19mm in height, 14.3mm in depth, and a solder pin length of 3.2mm. The part is made from Polyamide (PA66) with a flammability class of UL94 V0, chrome-nickel spring steel for the clamping spring, electrolytic copper with tin plating for contacts, and weighs 7g. It operates within a temperature range of -60 to +105°C, is RoHS compliant, and comes in a box of 140 pieces with the country of origin being CH.
