Powermatic Associates Logo

739-3204 WAGO Industrial Automation Components

739-3204 on Powermatic Associates
WAGO

Part#:739-3204

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

739-3204 WAGO - PCB terminal block; 2.5 mm²; Pin spacing 10 mm; 4-pole; CAGE CLAMP®; 2,50 mm²; gray

Product Details

  • Package Type
    Box
  • Conductor Size
    12 american wire gauge, 2.5 millimeters
  • Weight
    6.671 grams
  • Color
    Gray
  • Strip Length
    0.35 inches, 9 millimeters
  • Depth
    0.563 inches, 14.3 millimeters
  • Flammability Class
    V0
  • Contact Type
    Tin
  • Width
    1.437 inches, 36.5 millimeters
  • Contact Material
    Copper
  • Voltage
    1000 volts, 300 volts
  • Actuator
    Operating Tool
  • Height
    0.748 inches, 19 millimeters
  • Current
    20 amperes, 24 amperes
  • Insulation Material
    Polyamide

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
