K50BCLGRYNQ Banner Pick-to-Light Sensors

K50BCLGRYNQ on Powermatic Associates
Banner
  • K50BCLGRYNQ
  • K50BCLGRYNQ

Part#:K50BCLGRYNQ

Alt. Part#:802974

Manufacturer:Banner

Category:Pick-to-Light Sensors

Product Lifecycle:Active

Product description

K50 Beacon EZ-LIGHT: 3-Color Perimeter & Top View; Voltage: 12-30 V dc; Housing: Polycarbonate; IP69K; Input: NPN; Colors: Green Red Yellow; 5-pin M12 Integral QD

Product Details

  • Weight
    136.0776 g
  • Country Of Origin
    MX
  • Indication
    Yes
  • Number of Input Pins/Conductors
    5
  • Max Op. Temperature (°C)
    50
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Connection
    Integral QD
  • Physical Dimensions (LxWxH or DxH mm)
    50.0 x 60.0
  • Primary Housing Color
    Black
  • Housing Style
    Base Mount - Flat Window
  • Color Option 1
    Green
  • Environmental Rating
    IP67; IP69
  • Indication Intensity
    High Brightness & Daylight Visible
  • Mounting Thread
    M30 x 1.5
  • Quick Disconnect Type
    M12 (Euro)
  • NEMA Type and UL Type Rating
    NEMA 4X, 13
  • Feature: Audible
    No
  • Modbus RTU
    No
  • Power Source
    DC
  • Color Option 3
    Yellow
  • Max Op. Relative Humidity Non-Condensing (%)
    90% @ 50°C
  • Feature: Quick Disconnect
    Yes
  • Max Current Color (mA)
    110
  • Feature: Washdown Rated
    Yes
  • Primary Housing Material
    Polycarbonate
  • Number of Colors / Segments
    3
  • Color Technology
    Standard LED
  • Animation Option 1
    Solid On
  • Max Input Response Time (ms)
    10
  • Input Type
    NPN
  • Primary Window Material
    Polycarbonate Clear
  • Wireless
    No
  • Product Size (mm)
    50
  • Color Option 2
    Red
  • Feature: Hazardous Area
    No
  • Pro-Editor Compatible (Discrete)
    No
  • Power
    DC
  • Supply Voltage
    12-30 V dc
  • Min Op. Temperature (°C)
    -40
  • IO Link
    No
  • Feature: Chemical Resistant
    No
  • Multi-Color Device
    Single Color On

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of K50BCLGRYNQ on Powermatic Associates is $160.00. Order now.

About the product

Banner Engineering K50BCLGRYNQ is a high-intensity industrial LED light beacon from the EZ-LIGHT Beacons series, designed for both perimeter and top view lighting. This 1-tier, 3-color (Green/Red/Yellow) beacon features a round flat window with a black housing made from clear polycarbonate (PC) for the window and polycarbonate (PC) base for durability. It is pre-equipped with a 5-pin M12 Euro-style quick disconnect (QD) connector for easy installation. The beacon operates on a supply voltage of 12Vdc to 30Vdc, with 24Vdc nominal, and can be mounted via surface, base pole M30, or 1/2" NPSM thread. With a diameter of 50mm (2 inches), it is designed to function in ambient air temperatures ranging from -40°C to +50°C. This beacon offers a high degree of protection with ratings of IP67, IP69K, NEMA 4X, and NEMA 13, ensuring its suitability for harsh environments. It has a current consumption of 110mA and includes 3 digital inputs (12-30Vdc; NPN) for color control.
