K50APFF100GRCQ Banner Pick-to-Light Sensors
Part#:K50APFF100GRCQ
Alt. Part#:76229
Manufacturer:Banner
Category:Pick-to-Light Sensors
Product Lifecycle:Active
Product description
K50 C-Series EZ-LIGHT: 2-Color Fixed-Field Sensor; Voltage: 12-30 V dc; Housing: Polycarbonate; IP67 IP69K; Range: 100 mm; Input: PNP (NO); Colors: Green Red; 4-pin M12 Integral QD
Product Details
- Weight 158.7572 g
- Country Of Origin MX
- Mounting Thread M30 x 1.5
- Number of Input Pins/Conductors 4
- Environmental Rating IP67; IP69
- Min Op. Temperature (°C) -40
- Pro-Editor Compatible (Discrete) No
- Power Source DC
- Color Technology Standard LED
- Acknowledge (Sense) Light Red
- Max Output Response Time (ms) 3
- Primary Window Material Polycarbonate Diffused
- IO Link No
- Feature: Audible No
- Power DC
- Number of Colors / Segments 2
- Max Current Color (mA) 75
- Input Type PNP
- Number of Beams 1
- Feature: Chemical Resistant No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Animation Option 1 Solid On
- Pick-to-Light Function C
- Maximum Sensing Distance (mm) 100
- Feature: Washdown Rated Yes
- Modbus RTU No
- Actuation Yes
- Color Option 2 Red
- Supply Voltage 12-30 V dc
- Physical Dimensions (LxWxH or DxH mm) 50.0 x 67.8
- Primary Housing Color Black
- Wireless No
- Primary Housing Material Polycarbonate
- Color Option 1 Green
- I/O Block Compatible Yes
- Max Op. Temperature (°C) 50
- Multi-Color Device Single Color On
- Activation Function Optical
- Connection Integral QD
- Output Type PNP
- NEMA Type and UL Type Rating UL 4X, 13
- Job Light Green
- Button Operation Momentary
- Housing Style Base Mount - Dome Window
- Quick Disconnect Type M12 (Euro)
- Product Size (mm) 50
- Operation Normally Open
- Max Op. Relative Humidity Non-Condensing (%) 90% @ 50°C
- Feature: Hazardous Area No
- Sensing Mode (General) Fixed Field
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of K50APFF100GRCQ on Powermatic Associates is $159.00. Order now.
About the product
Banner Engineering K50APFF100GRCQ, part of the EZ-LIGHT series, is a pick-to-light device designed with a fixed field infrared (IR) sensing LED illumination. This unit features a black housing with a dome window shape, constructed from polycarbonate (PC) for both the diffused window and the base. It is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The device operates on a supply voltage of 12Vdc-30Vdc, with 24Vdc nominal, and offers versatile mounting options including surface, base pole M30, and 1/2" NPSM thread. The dome diameter measures 50mm / 2 inches, and it can operate in ambient air temperatures ranging from -40°C to +50°C. It boasts a high degree of protection with ratings of IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. The operating mode includes a momentary job light (G; Green) that is ON when the job input is active, and touch activates the output and sensing light (R; Red) with a NO (Normally Open) touch output. It features 1 x digital input (12-30Vdc; PNP) for JOB color control and a sensing distance of 100mm, along with 1 x digital output (12-30Vdc; PNP) for touch functions.
